Sensor
35.6 x 23.8 mm (Full-Frame) CMOS
Effective Megapixels
24.2 Megapixels
Recording Format
H.265/H.265 Long GOP/MOV 4:2:2 10-Bit:
4096 x 2160p at 23.98/25/29.97 fps (100 to 400 Mb/s)
3840 x 2160p at 23.98/25/29.97 fps (100 to 400 Mb/s)
3328 x 2496p at 23.98/24/25/29.97 fps (150 to 400 Mb/s)
1920 x 1080p at 23.98/29.97/59.94 fps (100 to 200 Mb/s)
1920 x 1080i at 50/59.94 fps (50 to 100 MB/s)
H.265/H.265 Long GOP/MOV 4:2:0 10-Bit:
5952 x 3968p at 23.98/24/25 fps (200 Mb/s)
5376 x 3584p at 25/29.97 fps (200 Mb/s)
5888 x 3312p at 23.98/25/29.97 fps (200 Mb/s)
4096 x 2160p at 23.98/24/29.97/48/50/59.94 fps (200 Mb/s)
H.265/H.265 Long GOP/MOV 4:2:0 10-Bit:
1920 x 1080p at 100/119.88 fps (150 Mb/s)
1920 x 1080p at 47.95/48 fps (100 Mb/s)
Shutter Speed
1/16000 to 1/2 sec
White Balance
2500 to 10,000K
Sensitivity
100 to 51,200 (Native)
80 to 204,800 (Expanded)
Built-In Microphone
Stereo
Power Supply
Panasonic AG-VBR Series
Dimensions
3.7 x 3.7 x 3.1" / 9.3 x 9.3 x 7.8 cm (Without Protrusions)
Recording Media
Dual Slot: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]
Raw Output
HDMI In Full Frame Mode:
5888 x 3312 12-Bit at 23.98/25/29.97 fps
HDMI In Super35 Mode:
4128 x 2176 12-Bit at 23.98/25/29.97/50/59.94 fps
3536 x 2656 12-Bit at 23.98/25/29.97/50 fps
IP Streaming
RTP, RTSP: 1280 x 2160 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 50.00 Mb/s)
Gamma Curve
Panasonic V-Gamut, Panasonic V-Log
Audio Recording
MOV: 24-Bit 48 kHz LPCM Audio
MOV: 24-Bit 96 kHz LPCM Audio
MP4: 24-Bit 48 kHz LPCM Audio
MP4: 24-Bit 96 kHz LPCM Audio
Sensor Windowing
6K (5952 x 3968) in 3:2
5K (5888 x 3312) in 16:9
5K (5376 x 3584) in 3:2
4K (4096 x 2160) in 17:9
4K (3840 x 2160) in 16:9
1080p (1920 x 1080) in 16:9
Video Connectors
1 x BNC (3G-SDI) Output
1 x HDMI (HDMI 2.0) Output
Audio Connectors
1 x BNC (3G-SDI) Output
1 x HDMI (HDMI 2.0) Output
Other I/O
1 x USB Type-C Camera Interface, USB 3.1 Gen 1 Data, Control, Video Input
1 x BNC Timecode Data Input/Output
1 x BNC Genlock Data Input/Output
1 x RJ45 LAN Control, Monitor, Video Input/Output
1 x 2.5 mm LANC Control Input
Wireless Interfaces
2.4 GHz Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g), Bluetooth Video Output, Control
Power Connectors
1 x Weipu SF610/S2 (12 VDC) Input
Operating Temperature
14 to 104 degrees F / -10 to 40 degrees C
Accessory Mount
9 x 3/8"-16 Female
1 x Hot Shoe Mount
Tripod Mounting Thread
2 x 3/8"-16 Female (Bottom)
Material of Construction
Aluminum
